| Operating system | Liunx3.10 (Full VISION T717,6 core CPU, 6*A7 1.2ghz) |
| Operating temperature | -30°C ~75 °C |
| Operating voltage | 16V ~ 32V |
| Rated current | ≤10A |
| Static current | ≤3.0mA |
| Master MCU | STM32F105RB |
| The core CPU | T717 |
| eMMC | KLMAG2GESD-B04p 16G |
| DDR3 | k4B4G1646D-BFMA 256*16=512 |
| BT/WIFI module | GOC - LR181 |
| LVDS unbuncher | THCV236 |
Note: Specific specifications are subject to the actual model of the manufacturer
| Radio | chip :TEF6638: global regional frequency band,A total of 30 AM/FM radio can be pre-stored, can automatically search the storage station, also can manually search and adjust the frequency |
| Bluetooth | Bluetooth 4.1, can support Bluetooth speaker, Bluetooth music, Bluetooth call, phone book download |
| GPS navigation | customer matching map can be supported (joint adjustment) |
| Mobile phone interconnection | support Carplay, Android Auto interconnection, Android phone support dual-screen interaction |
| Voice recognition | customers need to provide third-party application technical support |
| WIFI connection | Using the communication standard :IEEE802.118, transmission capacity of 100Mbps |
| Video | support DivX,MPEG-1,2,4 AVI, MP4 and other formats |
| Audio | support MP3, WMA, AAC, WAV and other formats; Can play USB audio files |
| Image | JPEG, BMP, PNG, etc |
| E-books | support reading PDF TXT files |
Note: Specific specifications are subject to the actual model of the manufacturer
